性能与特点

>设有液位开关、压力开关(可选配)。当油量或压力不足时可将异常信号输出。

>面板指示灯可显示出注油机的通电和润滑状态。系统中设有"FEED"键，可强制润滑。

>时间设定:单次最长润滑时间≤2min，间歇时间通常为润滑时间的5倍以上。

>电机设有自我保护功能，防止电机温度过高及过载。

>抵抗式系统中无脱压装置，需配合比例接头分配器使用(参考25~27页)。

>设有溢流阀，可保护注油机及管路由于压力过高而损坏。

>内部配有保险丝防止短路导致电流过大烧坏IC板和电机。

Performance and characteristics

·Liquid level switch and pressure switch (optional) are provided. When oil volt

Ume or pressure is insufficient, abnormal signal is output.

·The panel indicator light indicates power and lubrication status of the oil injection mold.

·The system is provided with FEED key,and compulsory lubrication is applied.

·Time setting: single maximum lubrication duration≤2min, and the intermittent time is at least 5 times of the lubricating time.

·The motor is provided with self-protection to prevent high temperature and overload of motor.

·No decompression device is provided with resistance-type system, usedwith proportional joint distributor (Refer to page 25~27).

·Overflow valve is provided to prevent damage by oil injector and pipeline

·Internal fuse is provided to prevent lC board and motor damaged by short circuit.
